Solid carbide tools
F4
Extended product range
New deep hole drilling concept
Process security & precision to depth
Trust the deep hole drilling specialist in the market. As deep
holes depend very much on the previously produced pilot hole,
Cutting Solutions by CERATIZIT has optimised the drilling pro-
cess with special geometries. Consequently, the chips can be
evacuated without the need to peck. This allows you to shorten
the cycle times and reduces the cost per hole. The adapted
pilot hole drilling operation increases process security and pro-
tects the deep hole drill from wear on the cutting edges. Your
added value: longer tool life.
Adapted pilot drill programme
Our deep hole drill programme includes specially developed
pilot drills which guarantee top performance and process secu-
rity even under difficult conditions and special drill lengths.
The new pilot drills for aluminium and universal machining
are tailored to and available for our standard deep hole drills.
For extra-long drilling tools (> 40xD), we have developed the
'co-pilot' drill.
New possibilities in the deep hole drilling process:
Pilot drill
ranges
Drilling length
Through-
coolant
W1106
UN
2 – 12
5xD 2x/4x
W1206
AL
2 – 12
5xD 2x
Tolerances
d1 = p6 / da = h6
Point angle
140°
Guide lands
4x
Grade
SCPP415
d1 = p6 / da = h6
140°
6x SCPN435
For difficult conditions for drilling depths starting at 40xD and special drilling lengths we recommend the following:
Co-pilot drill
ranges
Drilling length
Through-
coolant
Tolerances
Point angle
Guide lands
Grade
W1121
UN
3–9
20xD
2x
d1 = j6 / da = h6
138°
4x SCPP415
