MaxiMill HFC system

Customer benefit

B90

Minimum vibration

The light cutting geometry and the very positive angle allow

for reduced vibration of the milling system. The cutting forces

are mainly in axial direction. Even with long tool overhangs the

stress on the machine spindle is minimised.

Systems for high feed rates with approach angle kr = 15°

The axial forces produced are directed towards the machine

spindle:

Fr << Fa

Fa = axial force on the spindle

Fr = radial force on the spindle

Fres = resulting force on the spindle

Fres

hm fz x sin kr

Small approach angle kr

kr between 15 and 20°!

Low to mediume chip thickness hm

The smaller the approach angle, the lower the medium chip thickness.

High feed rate per tooth fz

In orer to reach a regular medium chip thickness, the feed rate per tooth

has to be increased.

Thanks to the small approach angle reducing chip thickness, high feed per tooth and high metal removal rates are

possible, even with small depths of cut.
