The universal tooling system UTS
The quick lock
A282
With the MaxiFlex UTS quick lock full actuation is achieved
by a 140° rotation of an eccentric cam.
The tried and tested principle of ball clamping is maintained,
but the defined clamping force is produced through disc
springs. Both, when clamping and releasing cutting heads,
the rotation of the cam is limited through a fixed stop.
Therefore a torque key is no longer necessary for the
MaxiFlex UTS quick lock.
1 clamped
2 clamping distance
3 clamped
140°
12
3
Special advantages
140° rotation of the key for clamping and unclamping
Considerably reduces tool changing times
Makes tool changing in difficult to access areas easier
Defined clamping forces through disc spring pack
Torque key NO LONGER NECESSARY
Constant clamping forces
More security and longer tool life
The possibilities of the MaxiFlex UTS quick lock are
particulary useful on lathes with frequent tool changes.
