The HSK-T tooling system
A283
What is HSK-T
The ‘T’ stands for ‘Turning’. The HSK-T has the shape of
a HSK taper, form A / C (ISO 12164-1 and 2) and can be
fundamentally distinguished from this taper by its consid-
erably closer tolerances of the driving grooves (tool) and
drive dogs (adapter).
In this way the radial positioning precision (tip height) which
is of decisive importance for turning is guaranteed. The
HSK-T is standardised according to ISO 12164-3 (outer taper
- tool) and -4 (inner taper - adapter).
HSK - A/C
A HSK - T
A AA
A
Benefit
tip height
f
d1
Perfect accuracy – also when it comes to the tip
height
The positioning of the cutting edge, in HSK-T63, f = 45 mm is thus
reduced to ±0.13 mm and in HSK-T100, dimension f = 55 mm to
±0.11 mm.
Applicable on all machines with HSK-T or HSK-A
spindle
In all CERATIZIT HSK-T tools the dimensions d1 and l2 comply with
ISO 12164-1 (HSK-A).
Therefore they can also be applied and automatically changed on
machines which are designed for HSK-A tools.
